Figure 62. Keypad navigation chart
7.3.1 Monitoring menu (M1)
You can enter the Monitoring menu from the Main menu by pushing the Menu button right when the
location indication M1 is visible on the first line of the display. How to browse through the monitored
values is presented in Figure 63.
The monitored signals carry the indication V#.# and they are listed in Table 49. The values are
updated once every 0.3 seconds.
This menu is meant only for signal checking. The values cannot be altered here. For changing values
of parameters see Chapter 7.3.2.
