Control keypad vacon • 121
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
7
Figure 63. Monitoring menu
NOTE! The All in One applications embody more monitoring values.
Table 49. Monitored signals
Code Signal name Unit Description
V1.1 Output frequency Hz Frequency to the motor
V1.2 Frequency reference Hz
V1.3 Motor speed rpm Calculated motor speed
V1.4 Motor current A Measured motor current
V1.5 Motor torque % Calculated motor shaft torque
V1.6 Motor power % Calculated motor shaft power
V1.7 Motor voltage V Calculated motor voltage
V1.8 DC-link voltage V Measured DC-link voltage
V1.9 Unit temperature ºC Heat sink temperature
V1.10 Motor temperature %
Calculated motor temperature. See VACON
®
NX All in One applica-
tion manual.
V1.11 Voltage input V AI1
V1.12 Current input mA AI2
V1.13 DIN1, DIN2, DIN3 Digital input statuses
V1.14 DIN4, DIN5, DIN6 Digital input statuses
V1.15 DO1, RO1, RO2 Digital and relay output statuses
V1.16 Analogue output current mA AO1
V1.17 Multimonitoring items Displays three selectable monitoring values. See Chapter 7.3.6.5.
V1 V14
READY
Local
13.95 Hz
READY
Local
13.95 Hz
READY
Lo ca l
RUN RU N
RUN
Monitor Output frequency
FreqReference
11376_uk
