X5 AC Drive User’s Manual Chapter 7: X5 Parameters
DPD00089A - 97 - © 2009 Vacon Incorporated All Rights Reserved
743 Thres 2 Select
Default: 15 (Curr High)
Range: n/a
Level 2
This parameter selects the type of threshold to be used for Threshold 2.
Parameter Value
Description Parameter Value Description
0 Vin 1 High 11 Load In
1 Vin 1 Low 12 Power High
2 Vin 1 In 13 Power Low
3 Vin 2 High 14 Power In
4 Vin 2 Low 15 Curr High
5 Vin 2 In 16 Curr Low
6 Cin High 17 Curr In
7 Cin Low 18 Enc % High
8 Cin In 19 Enc % Low
9 Load High 20 Enc % In
10 Load Low
For detailed information about setting up Threshold parameters, see “Thresholds” on page 58.
744 Thres 2 High
Default: 100.00%
Range: -300.00% to 300.00%
Level 2
This parameter sets the High Thres level for Threshold 2. For detailed information about setting up Threshold
parameters, see “Thresholds” on page 58.
745 Thres 2 Low
Default: 0.00%
Range: -300.00% to 300.00%
Level 2
This parameter sets the Low Thres level for Threshold 2. For detailed information about setting up Threshold
parameters, see “Thresholds” on page 58.
746 Timer 1 Type
Default: 0 (On Delay)
Range: n/a
Level 2
This parameter defines the configuration of Timer #1 that you want the drive to emulate.
Parameter Value
Description
0On Delay
1Off Delay
2On/Off Delay
For detailed information about setting up Timer parameters, see “Timers” on page 58.
747 Timer 1 Signal
Default: DI-REV
Range: n/a
Level 2
This parameter selects the function that the timer is counting; it includes any function listed in the digital input list.
See Parameter 705, Relay 1 Select, on page 93 for the list of options. For detailed information about setting up Timer
parameters, see “Timers” on page 58.
748 Timer 1 Time
Default: 1.0 sec
Range: 0.0-320.0 sec
Level 2
This parameter specifies the duration of time in seconds for the timer to count. For detailed information about setting up
Timer parameters, see “Timers” on page 58.
749 Timer 2 Type
Default: 0
Range: n/a
Level 2
This parameter selects the kind of timer to be used, as shown in the following options:
Parameter Value
Description
0On Delay
1Off Delay
2On/Off Delay
For detailed information about setting up Timer parameters, see “Timers” on page 58.
Table 7-2: Description of X5 Parameters (Page 27 of 40)
