Calibrating the Generator
5-24 Force FX-8C Service Manual
Calibrating the Generator
There are eight calibration steps. During calibration you verify
information specific to the generator, adjust the date, and adjust the clock.
You also adjust the REM circuit and several values, or factors, that ensure
the proper operation of the generator.
The calibration steps and the values you can adjust are summarized
below. Certain values are not adjustable but must be verified.
Notice
After completing any calibration step, proceed to the next step to save the values
from the completed calibration step.
Calibration Step and Description Adjustable?
1 Force FX-8C generator data
Generator model number
Master microcontroller software version
Feedback microcontroller software version
No (verify value)
No (verify value)
No (verify value)
2 Calendar
Month
Day of the month
Year
Yes
Yes
Yes
3 Clock
Hour
Minute
Yes
Yes
4 REM oscillator frequency and impedance Yes
5 Current sense gain factor Yes
6 Voltage sense gain factor Yes
7 Reactance gain factor Yes
8 ECON factor Yes
