Front Panel Assembly
9-8 Force FX-8C Service Manual
Parts List
Item Description Part Number
4 Switch 243 025 037
5 Tubing, heatshrink 1 inch ID 249 001 010
6 Bipolar bracket 223 500 077
7 Tape, foam one-sided 1/16 x 1/4 232 301 185
8 Cable assembly, REM 202 701 854
9 REM retaining plate 223 400 243
10 Screw, panhead Phillips M3 x 0.5 x 12 zinc 237 050 135
11 Washer, lock internal metric M3 253 300 044
12 Assembly, display board
See Display Board Components in this section.
201 345 001
13 Screw, thread forming #4-20 0.625 237 050 147
14 Display board spacer 223 400 626
15 Cable assembly, power switch 207 500 213
16 Shroud, bipolar 223 100 998
17 Assembly, CEM switch
Includes
Switch support lever
Lever switch
Spring compression
Assembly, cable switch CEM
202 701 868
223 100 975
223 100 974
223 500 076
202 701 867
18 Adhesive, prism 405 232 301 149
19 Washer, flat M3 253 300 004
Not shown:
Overlay jack 216 150 613
Keyboard front 207 500 597
Control panel 223 100 978
