Setting Up the Generator
Setup, Tests, and Adjustments
Force FX-8C Service Manual 5-5
Figure 5-2.
Bipolar or macrobipolar connection—
handswitching instrument
Setting the Bipolar Output
1. (Optional) To display the previous settings, press the Recall button.
2. To set the Bipolar mode, press the Precise, Standard, or Macro button.
The corresponding indicator illuminates green.
3. To increase the power for the selected mode, press the white up arrow
( ∆ ) button. To decrease the power, press the white down arrow ( ∇ )
button. The maximum power setting is 70 watts.
Caution
Set power levels to the lowest setting before testing an accessory.
Handswitching instrument
