Valleylab Force FX-8C - Figure 3-12. Blend Cut Mode-Output Power Vs. Peak Voltage

Output Power vs. Resistance Graphs
Technical Specifications
Force FX-8C Service Manual 3-19
Figure 3-11.
Output power versus impedance for
Blend cut mode
Figure 3-12.
Blend cut mode—
output power vs. peak voltage
0 200 400 600 800 1000 1200 1400 1600 1800 2000
250
225
200
175
150
125
100
75
50
25
0
200 W
100 W
Load Resistance (ohms)
Output Power (watts)
Output Power (watts)
Open Circuit Peak Voltage (volts)
