Valleylab Force FX-8C - Parts List

Generator Assembly
9-4 Force FX-8C Service Manual
Parts List
Item Description Part Number
1 Chassis, lower 223 200 609
2 Assembly, footswitch board
See Footswitch Board Components in this
section.
201 347 003
3 Cable assembly, line filter
Includes
Cable, filter line ground
Cable, filter line
Tubing, heatshrink black 1/4 ID
Line filter, 10 amp
Fuse, 4A, 5x20 mm Slow Blow
Sleeving, PVC clear 11 awg
202 701 983
207 500 544
207 500 543
249 001 002
251 400 007
215 100 074
249 014 012
4 Handle, collapsible tray 223 300 054
5 Rubber foot 213 400 082
6 Equipotential ground lug 208 200 141
8 Screw, Phillips M4 x 0.7 x 10 237 050 139
9 Sealant, loctite #222 232 301 148
10 Screw, pnh phh M4 x 0.7 x 8 mm 237 050 113
11 Washer, lock internal metric M4 253 300 045
12 Screw, panhead Phillips M3 x 0.5 x 12 zinc 237 050 135
13 Washer, lock internal metric M3 253 300 044
14 Screw, panhead M3 x 0.5 x 8 zinc 237 050 149
15 Lockwasher, M6 ext tooth 253 300 000
16 Nut, hex M6 x 10 brass nickel plated 224 300 000
21 Assembly, front panel
See Front Panel Assembly in this section.
202 701 978
22 Assembly, control board
See Control Board Components in this section.
201 500 011
23 Cover, upper 223 200 610
