Valleylab Force FX-8C - Footswitch Board Components

Footswitch Board Components
Service Parts
Force FX-8C Service Manual 9-11
Footswitch Board Components
Integrated Circuits
U4, U5, U7,
U8, U9, U11,
U12, U13
LED 7-segment display HDSP560/green 239 750 071
Miscellaneous (not shown)
Clip, display board 213 130 033
Socket, dip 20-pin gold 208 500 054
Socket, dip 30-pin gold 208 500 055
Socket, I.C. 16-pin 208 121 003
Reference
Designator Description
Valleylab
Part Number
Reference
Designator Description
Valleylab
Part Number
Capacitors
C1, C2, C12,
C13, C14, C16,
C17, C18, C21,
C29, C30, C31,
C32, C33
.01 µF ± 10%, 100 V 204 200 457
C3, C4, C5, C6,
C7, C8, C15,
C19, C20, C22,
C23, C24, C25,
C26, C28, C34,
C36, C37
1 µF ± 10%, 100 V 204 200 509
C9, C10, C27 22 µF ± 20%, 25 V 204 600 063
C11 1 µF ± 20%, 50 V 204 200 464
C35 .022 µF ± 10%, 100 V 204 200 501
C38, C39, C40,
C41, C42, C43,
C44, C45, C46
.01 µF ± 10%, 500 V 204 200 547
