Footswitch Board Components
9-12 Force FX-8C Service Manual
Diodes
D1, D2 1N4148 239 014 000
Transistors
Q1 FET VN0808L 239 200 039
Resistors
R1, R2, R3,
R4, R7, R9
10 kΩ ± 5%, 1/4 W 234 024 087
R5, R18, R19,
R31
10 kΩ ± 1%, 1/8 W 234 201 385
R6, R10 6.8 kΩ ± 5%, 1/4 W 234 024 083
R8, R15, R22,
R23, R26, R29
2 kΩ ± 5%, 1/4 W 234 024 070
R11 432 Ω ± 1%, 1/4 W 234 201 254
R12 Pot, 5 kΩ 236 200 103
R13, R16,
R20, R24, R27
1.4 kΩ ± 1%, 1/8 W 234 201 303
R14, R17,
R21, R25, R28
2.15 kΩ ± 1%, 1/8 W 234 201 321
R30 19.6 kΩ ± 1%, 1/8 W 234 201 413
R32 200 kΩ ± 1%, 1/4 W 234 201 510
R33 5.11 kΩ ± 1%, 1/8 W 234 201 357
R34 56 kΩ ± 5%, 1/4 W 234 024 105
R35 100 kΩ ± 5%, 1/4 W 234 024 111
Integrated Circuits
U1 LM339AN 210 300 015
U2 DC/DC converter HPR107 210 750 007
Reference
Designator Description
Valleylab
Part Number
