Valleylab Force FX-8C - Bipolar Controls

Bipolar Controls
Controls, Indicators,
and Receptacles
Force FX-8C Service Manual 2-3
Bipolar Controls
Figure 2-2.
Buttons and indicators for bipolar
controls
Bipolar indicator
When you activate bipolar, this
indicator illuminates blue and an
activation tone sounds.
Power buttons
Press
∆ to increase the power.
Press
∇ to decrease the power.
Macro mode button
Select for macrobipolar output.
Standard mode button
Select for standard bipolar
tissue desiccation.
This is the default bipolar mode.
Precise mode button
Select for fine bipolar tissue
desiccation.
Bipolar display
Shows the power setting, in watts,
for the selected mode.
Mode indicators
Illuminate green when you press
the corresponding mode button.
