Valleylab Force FX-8C - Power Supply;Rf Board Components

Power Supply/RF Board Components
9-18 Force FX-8C Service Manual
Power Supply/RF Board Components
35 Ties, Cable, wire 222 004 007
Not Shown:
Tubing, heat shrink 3/8 ID 249 001 003
Cable assembly, 4-wire power 207 500 210
Cable assembly, 3-wire power 207 500 211
Item Description Part Number
Reference
Designator Description
Valleylab
Part Number
Capacitors
C1, C90 100 pF ± 5%, 100 V 204 200 452
C2, C43, C46,
C48, C52, C58,
C65, C71, C82,
C84, C86,
C117, C118,
C156, C170,
C172
.01 µF ± 20%, 50 V 204 200 456
C3, C10, C11,
C22
680 µF, 400 V 204 500 163
C4, C12, C13,
C44, C50, C91,
C93, C94, C96,
C97, C98, C99,
C102, C132,
C134, C137,
C139, C140,
C141, C144,
C145, C146,
C148
.01 µF ± 10%, 100 V 204 200 457
C5, C6, C7,
C14, C15, C16,
C17, C18, C19,
C20, C21, C23
1000 pF ± 5%, 100 V 204 200 454
