Force FX-8C Service Manual xi
Figure 5-1. Bipolar or macrobipolar connections—footswitch activation and a
handswitching or footswitching instrument 5-4
Figure 5-2. Bipolar or macrobipolar connection—handswitching
instrument 5-5
Figure 5-3. Monopolar connection—footswitch activation and a footswitching or
handswitching instrument using Monopolar 1 Footswitch receptacle
and Monopolar 1/CEM Instrument receptacle 5-6
Figure 5-4. Monopolar connection—footswitch activation and a footswitching or
handswitching instrument using Monopolar 2 Footswitch receptacle
and Monopolar 2 Instrument receptacle 5-7
Figure 5-5. Monopolar connection—handswitch activation and a monopolar
handswitching instrument using either Monopolar Instrument
receptacle
5-7
Figure 5-6. Connections for simultaneous coag—two handswitching
instruments 5-9
Figure 5-7. Connection for simultaneous coag—two footswitching
instruments 5-9
Figure 5-8. Connections for combined monopolar/ultrasonic surgery 5-10
Figure 5-9. Leakage current test circuit per IEC 60601-1 5-21
Figure 7-1. Removing and disconnecting the power switch 7-12
Figure 7-2. Replacing fuses in the fuse drawer 7-13
Figure 7-3. Replacing left front heat sink components 7-16
Figure 7-4. Components of the left rear heat sink 7-18
Figure 7-5. Components of the right heat sink 7-21
Figure 7-6. Low voltage power supply 7-24
Figure 7-7. Cable connections on the power entry module 7-26
Figure 9-1. Generator assembly 9-2
Figure 9-2. Generator assembly – continued 9-3
Figure 9-3. Front panel assembly 9-6
Figure 9-4. Front panel assembly – continued 9-7
Figure 9-5. Power Supply/RF board assembly 9-14
Figure 9-6. Power Supply/RF board assembly – continued 9-15
Schematics Supplement
Schematic 1. Control board layout S-1
Schematic 2. Control board schematic, page 1 of 3 S-2
Schematic 3. Control board schematic, page 2 of 3 S-3
Schematic 4. Control board schematic, page 3 of 3 S-4
Schematic 5. Display board layout S-5
