Valleylab Force FX-8C - Page 208

Power Supply/RF Board Components
9-20 Force FX-8C Service Manual
C40, C41, C60 15000 pF ± 5%, 500 V 204 300 132
C42 1500 pF ± 5%, 100 V 204 200 487
C54, C81,
C104
47 µF ± 20%, 50 V 204 200 463
C63, C68 22 pF ± 5%, 100 V 204 200 450
C69, C77 .1 µF ± 10%, 100 V 204 200 509
C73, C75 33 pF ± 5%, 100 V 204 200 451
C79, C107 1000 pF ± 5%, 100 V 204 200 485
C105, C108 .047 µF ± 20%, 50 V 204 200 517
C119, C126,
C129
6800 pF ± 5%, 100 V 204 200 495
C150, C151,
C158, C159
3900 pF ± 5%, 500 V 204 301 044
C152 3300 pF ± 5%, 500 V 204 105 038
C154, C157 .0047 µF ± 10%, 2000 V 204 200 548
C155, C169 .68 µF, 100 V 204 450 004
C171 10 µF ± 20%, 25 V 204 600 067
C174 470 pF ± 5%, 100 V 204 200 481
Diodes
CR1 1N4007 239 500 013
CR3, CR4,
CR5, CR6,
CR7, CR8,
CR12, CR15,
CR17, CR18,
CR25, CR26,
CR27, CR28,
CR34, CR37,
CR39, CR41,
CR47, CR48,
CR49, CR50
1N4148 239 014 000
Reference
Designator Description
Valleylab
Part Number
