Power Supply/RF Board Components
9-22 Force FX-8C Service Manual
R5, R6 30 kΩ ± 5%, 3 W 234 100 180
R7 91 kΩ ± 5%, 1/4 W 234 024 110
R8, R169 390 Ω ± 5%, 1/4 W 234 024 053
R9 10 Ω ± 5%, 1 W 234 022 015
R10 63.4 kΩ ± 1%, 1/8 W 234 201 462
R11, R17,
R20, R25,
R39, R41,
R75, R79,
R87, R92,
R101, R106,
R144, R146,
R147, R152,
R155
1 kΩ ± 5%, 1/4 W 234 024 063
R12, R18,
R21, R26,
R131, R136,
R140
51 Ω ± 5%, 1/4 W 234 024 032
R13, R14,
R15, R42,
R45, R48,
R55, R67,
R86, R91,
R93, R99,
R100, R107,
R108, R111,
R112, R122,
R130, R132,
R133, R134,
R137, R142,
R143, R170,
R173
10 kΩ ± 5%, 1/4 W 234 024 087
R113, R114,
R115,
820 Ω ± 5%, 1/4 W 234 024 061
R16 4.75 kΩ ± 1%, 1/8 W 234 201 354
R19, R109 Thermistor, 10 kΩ, 25 C 240 003 006
R22, R23 10 Ω ± 5%, 1/2 W 234 014 068
Reference
Designator Description
Valleylab
Part Number
