Valleylab Force FX-8C - Page 212

Power Supply/RF Board Components
9-24 Force FX-8C Service Manual
R61, R64,
R74, R81
1 kΩ ± 1%, 1/8 W 234 201 289
R62, R82 499 Ω ± 1%, 1/8 W 234 201 260
R68 510 Ω ± 5%, 1/4 W 234 024 056
R76 100 Ω ± 1%, 2 W 234 400 276
R77 221 Ω ± 1%, 1/8 W 234 100 181
R78 280 Ω ± 1%, 1/8 W 234 201 236
R80 62 kΩ ± 5%, 1/4 W 234 024 106
R83, R84 249 Ω ± 1%, 1/8 W 234 201 231
R88 6.8 kΩ ± 5%, 1/4 W 234 024 083
R89 5.1 kΩ ± 5%, 1/4 W 234 024 080
R90 3.9 kΩ ± 5%, 1/4 W 234 024 077
R94 56.2 kΩ ± 1%, 1/8 W 234 201 457
R95, R151,
R156, R158,
R162, R163,
R165
10 kΩ ± 1%, 1/8 W 234 201 385
R96 Trimpot, 5 kΩ 236 200 078
R97 301 Ω ± 1%, 1/4 W 234 201 239
R98 Thermistor, 1 k /25C 2% 240 003 008
R103 47 Ω ± 5%, 1/4 W 234 024 031
R105, R139,
R141
100 kΩ ± 5%, 1/4 W 234 024 111
R110 2.15 kΩ ± 1%, 1/8 W 234 201 321
R120 3.16 kΩ ± 1%, 1/8 W 234 201 337
R123 270 kΩ ± 5%, 1/4 W 234 024 121
R124 750 Ω ± 5%, 1/4 W 234 024 060
Reference
Designator Description
Valleylab
Part Number
