Power Supply/RF Board Components
9-26 Force FX-8C Service Manual
U6 Quad 2 input 4093B 210 250 094
U7 Op-amp Max 492CPA 210 100 035
U8, U10, U11,
U12, U23
Dual op-amp AD827 210 400 023
U14 Multivibrator 74LS221 210 520 094
U15, U16 2803A 210 800 002
U18, U21 Op-amp LF412 210 400 016
U22 Multiplexer DG508 210 800 036
U24 LM319 210 410 001
U25, U31 Op-amp TL052A 210 400 020
U28 Quad analog switch 210 200 041
U29 4081 210 210 081
U30 Inv, hex 74HC14 210 230 004
Miscellaneous
D1 Thermistor, triac AVS 12 CB 239 610 023
J18, J19 Contact, monopolar 223 500 085
J20 Bipolar contact spring 223 500 078
J21, J22, J23,
J24, J25, J26,
J27, J28
Fuse clip 215 100 078
FB1, FB2, FB3,
FB4, FB5, FB6,
FB7, FB8, FB9,
FB10, FB11,
FB12
Ferrite bead 251 100 116
L1 Inductor, 0.75 MH 251 100 107
OPT1, OPT2,
OPT3, OPT4,
OPT5
Optoisolator, single 239 750 073
Reference
Designator
Description
Valleylab
Part Number
