Setting Up the Generator
Setup, Tests, and Adjustments
Force FX-8C Service Manual 5-7
Figure 5-4.
Monopolar connection—footswitch
activation and a footswitching or
handswitching instrument using
Monopolar 2 Footswitch receptacle
and Monopolar 2 Instrument
receptacle
Figure 5-5.
Monopolar connection—handswitch
activation and a monopolar
handswitching instrument using either
Monopolar Instrument receptacle
Monopolar
footswitch
Patient return electrode
Footswitching or
handswitching
instrument
Patient return electrode
Handswitching
instrument
