1 Meaning of symbols

There are several symbols in the document:

Symbol Description

Not available for SPC42xx, SPC43xx.

Only available for SPC controller with IP interface

(SPC43xx/SPC53xx/SPC63xx).

Not available for installation type Domestic.

Only available in unrestricted mode.

Find further information about Security Grade, Region or Mode in text.

See Appendix for further information.
