– XBUS medical
– XBUS Power supply link
– XBUS output tamper
– XBUS Low voltage
– Engineer restore Required
– Autoarm
l System information
– Soaked zones
– Open zones
– Area state
– Low battery (sensor)
– Sensor lost
– WPA* low battery
– WPA* lost
– WPA* test overdue
– Camera offline
– Fob low battery
– Xbus over current
– Installer name
– Installer phone
– Engineer enable
– Manufacture enable
– Reboot
– Hardware fault
– Aux over current
– Battery low
– Ethernet link
– System name
* A WPA is compatible with SiWay RF Kit (SPCW110, 111, 112, 114 ) only.
12.1.3 Data entry on the LCD keypad
Entering data and navigating the menus on the LCD keypad is facilitated through the use of the
programming interface. The use of the interface for each type of operation is detailed below.
Entering numeric values
In Numeric Entry mode, only the numeric digits (0–9) can be entered.
l To move the position of the cursor one character to the left and right respectively, press the left and
right arrow keys.
l To exit from the feature without saving, press the BACK menu key.
l To save the programmed setting press ENTER or OK.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Keypad user interface
© Vanderbilt 2018 98 A6V10276959-d
11.2018
