Event
Queue
List of the events currently in the Event Queue. The tables shows the
following:
l Event Seq No.
l Event Timestamp
l Event Description
l Additional Event Info
l Start Timestamp
l Report Duration
Event Log Event log history for all the events that have occurred on the ATS. The table
shows the same fields as Event Queue above and the following additional
field:
l Event Seq No.
l Event Timestamp
l Event Description
l Additional Event Info
l Result
l Reported ATP
l Start Timestamp
l ACK/Fail Timestamp
l Report Duration
Network
Log
Network log for the ATS showing the configured polling interval.
Status of
ATPs within
ATS
This table shows each ATP in the ATS. For each ATP, the table shows the
ATP sequence number, the ATP name, the communications interface, ATP
Status, Last successful transmission, Network Log, ATP Log and Test Call
button.
Network Log: Click this button to show the network log.
ATP Log: Shows a list of poll transmissions. Click the Refresh button to
update the log. Click the Most Recent Last button to change the viewing
order. By default the most recent event displays first.
Manual Test button: Click this button to force a test call. The Event is added
to the event queue.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 193 A6V10276959-d
11.2018
