Vanderbilt SPCA210.100 User Manual

Zone Type
Processing
Category
Description
KEYARM Intruder This zone type is normally used in conjunction with a key lock mechanism.
A Keyarm can be configured to perform the following Setting Options:
l Fullset
l Partset A
l Partset B
A Keyarm zone will SET the System/Area/Common Areas according to the
selected Setting Option when it is OPENED and will UNSET the
System/Area/Common Areas according to the selected Setting Option
when it is CLOSED.
l If the zone with the keyarm zone type is assigned in an non area system
then the keyarm operation will SET/UNSET the system.
l If the zone with the keyarm zone type is assigned to an area then the
keyarm operation will SET/UNSET the area.
l If the zone with the keyarm zone type is assigned to a common area
then the keyarm operation will SET/UNSET all the areas in the common
area.
l If the ‘Open only’ attribute is set then the armed status of the
System/Area/Common Areas will toggle on each opening of the key
lock (that is, Open once to SET the system, Close and Open again to
UNSET).
l If the ‘Fullset Enable’ attribute is set then zone activation will only
Fullset the system.
l If the ‘Unset Enable’ attribute is set then zone activation will only unset
the system.
Keyarming will force set the system/area and auto-inhibit any open zones or
fault conditions.
Note: Your system will not comply with EN standards if you enable
this zone type to set the system without first entering a valid PIN on
an external device.
SHUNT Intruder This zone type is only available in Commercial Mode of operation. Though
the Shunt Alarm Zone type can be set in Domestic Mode of operation, it has
no effect.
This zone type when opened inhibits all zones that have the shunt attribute
set. This operation applies for both SET and UNSET modes. As soon as the
shunt zone is closed, the zones with the shunt attribute set will become un-
inhibited again.
X-SHUNT Intruder This zone type is only available in Commercial Mode of operation.
A zone programmed with the x-shunt zone type inhibits the next consecutive
zone on the system whenever it is opened. This operation applies for both
SET and UNSET modes. As soon as the x-shunt zone type is closed the
next zone becomes de-inhibited again.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Appendix
© Vanderbilt 2018 381 A6V10276959-d
11.2018
