Transmission time, max. values M0 – M4
Reporting time T3 as max.
Availability See ATS levels and attenuation specifications on page388.
Signalling security level Tested to EN50136-1-1 and classified as ‘S0’.
3.6 Compliance with VdS approvals
This installation document encompasses the required product installation information for VdS
approvals.
Vanderbilt
SPC42xx/43xx/53xx/63xx : VdS Approval Nr. G 112104, G112124, and G112128. VdS EN Certificates
EN-ST000142, EN-ST000143, EN-ST000055, EN-ST000056, EN-ST000057, EN-ST000058, EN-
ST000061, EN-ST000062.
Siemens
SPC42xx/43xx/53xx/: VdS Approval Nr. G116035. VdS EN Certificates EN-ST000225, EN-
ST000226, EN-ST000227, EN-ST000228, EN-ST000229, EN-ST000230, EN-ST000231, EN-
ST000232.
This section describes the compliance of this system with VdS approvals.
Configuring software for VdS compliance
To set the system for VdS compliance, do the following:
1. Log on to the panel with the browser.
2. Click Full Engineer.
3. Click Configuration > System > Standards.
4. Select Europe in the Continent section of the page.
5. Select Germany in the Region Compliance section of the page.
6. Select the VDS grade required by your installation type.
Hardware Fault reporting — in Configuration > System > System Options, you must select the
Enabled + Reporting (10s) option from the Watchdog Output Mode drop-down list.
Hardware faults are not reported if the Engineer is logged in to the system.
Hardware
VdS compliance requires the following:
l A G5 housing with Front tamper implemented as a minimum requirement.
l Keypads do not show status information if the system is armed.
l The number of supported zones is as follows:
– 512 zones in ring configuration
– 128 zones per X-Bus in multi-drop (spur) configuration
l The following end of line resistance combinations do not comply with VdS standards:
– 1k, 470 ohm
– 1k, 1k, 6k6 ohm
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Directives and standards
© Vanderbilt 2018 28 A6V10276959-d
11.2018
