To comply with NF and A2P installation regulations, this housing must be sealed by affixing the
accompanying Tamper Label after installation.
SPC products listed have been tested according to NF324 - H58, with reference to RTC50131-6 and
RTC50131-3 and current EN certifications, see Compliance with EN50131 Approvals on page20.
Product Type Configuration Standard Logo
SPC6350.320 + SPCP355.300
(Cert. 1233700001 + Cert.8033700002)
60h, unmonitored NF Grade 3,
Class 1
SPC5350.320 + SPCP355.300
(Cert. 1233700001 + Cert.8033700002)
60h, unmonitored
SPC6330.320 + SPCP333.300
(Cert. 1233700001)
60h, unmonitored NF Grade 3,
Class 1
SPC5330.320 + SPCP333.300
(Cert. 1232200003)
60h, unmonitored
7.1.5 PSU LED Status
The following table lists the Smart PSU LED status information:
LED MAINS
BATT 1
and 2
FUSE LIMIT STATUS
COLOUR Green Green Red Red Green
Condition
Normal On On Off Off On
Mains OK, battery charging On Flash On
Mains Fail, Battery OK Off On On
Mains OK, battery faulty or not present On Off On
Mains OK, battery faulty, not present, or in deep discharge
protection mode
All LEDs Off.
Fuse Fail On On
Total Load Current exceeded On On
PSU switcher failure Off Off Off Off Flash
7.1.6 System Recovery
Mains and Battery Failure
In the event of both mains and battery power failure, the PSU kickstart switch (item 25 in SPCP355.300
Smart PSU on page57) enables the system to be restarted if only battery power is reinstated. To kickstart
the system, do the following:
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Smart PSU
© Vanderbilt 2018 66 A6V10276959-d
11.2018
