The keypad buzzer sounds continuously for approximately 2 seconds to indicate that the zone
activation has been detected and the number of zones left to test (displayed on the keypad)
decreases.
4. Continue with the remaining zones on the system until all zones have been tested. If a zone
activation does not get acknowledged by the system, check the wiring of the sensor and/or replace
with another sensor if necessary.
NOTICE: All zones can be included in an Engineer walk test.
16.14.3 Zone Monitor
The Zone Monitor option displays status information on each of the zones on the system.
To view zone status information:
1. Scroll to TEST > ZONE MONITOR.
2. Press SELECT.
3. Scroll to a preferred zone and press SELECT.
The status of the zone and its associated resistance value is displayed.
4. Press NEXT to locate the zone (for example, CONTROLLER1=firstzone on Controller).
See the table below for correlating status information (valid for Dual EOL resistors).
Zone status Abbreviation
UNKNOWN UK
CLOSED CL
OPEN OP
SHORT SH
DISCONNECTED DI
PULSE PU
GROSS GR
MASKED AM
FAULT FA
DC SUB DC
OUT OF BOUNDS OB
UNSTABLE US
All zones on a system can be monitored for correct operation by performing a monitoring test.
To perform a zone monitoring test:
1. Scroll to ZONE MONITOR.
2. Press SELECT.
3. Scroll to a preferred zone and press SELECT, or enter the zone number directly.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the keypad
© Vanderbilt 2018 163 A6V10276959-d
11.2018
