Editing EDP Receiver Settings
1. Select Communications > Reporting > EDP > Edit.
The following page will be displayed.
2. Configure the fields as described in the table below.
Description Edit the name of the EDP receiver. Maximum 16 characters.
Receiver ID Edit the EDP receiver ID. Range is 1 to 999997 (999998 and 999999
are reserved for special purposes)
Protocol Version Select the EDP protocol version to use with this EDP receiver. Options
are Version 1 or Version 2. Version 2 is recommended if supported by
the receiver, as it is a more secure protocol.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 329 A6V10276959-d
11.2018
