System Configuration File
The following options are available to manage the system configuration file:
Download Downloads a configuration file from the controller.
Note: If an error message appears after clicking the download button, proceed as follows:
1. Select Internet Options in the Tools menu.
2. Select the Advanced tab.
3. Select the checkbox Do not save encrypted pages to disk.
4. Click Apply.
5. Click OK.
6. Click Download again.
When downloading a configuration file, the configuration settings are stored in a .cfg file. This file
can then be uploaded to other controllers to avoid lengthy programming procedures.
Upload Uploads a configuration file to the controller.
Backup Stores a backup copy of the current configuration to flash.
Restore Restores a backup copy of the current configuration from flash.
Users Data
The following options are available to manage users data:
Download Click the button to Download the users data from the panel. A dialog box asks you where you
would like the save the users.csv file.
Upload Click the Browse button to Upload users data to the panel. This must be a .csv file format.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 342 A6V10276959-d
11.2018
