Vanderbilt SPCA210.100 User Manual

Auxiliary power (nominal) Max. 2360mA at 12V DC (8 separately fused outputs, max. 300mA per output)
Battery type
(Battery not supplied)
l FIAMM FGV22703 (12V/27Ah) - NF
l YUASA NP17-12FR (12V/17Ah)
l YUASA NPL24-12IFR (12V/24Ah)
l Alarmcom AB1227-0 (12V/27Ah)
l PowerSonic PS12170 (12V/17Ah)
l PowerSonic PS12260 (12V/26Ah)
l YUASA Yucel Y17-12IFR (12V/17Ah)
l YUASA Yucel Y24-12FR (12V/24Ah)
Tamper contact Front/back tamper switch
Operating temperature 0 to +40°C
Housing Metal housing (1.5mm mild steel)
Colour RAL 9003 (signal white)
Dimensions 498 x 664 x 157mm
Weight (without batteries) 18.400kg (housing incl. cover), 11.300kg (housing without cover)
IP/IK Rating 30/06
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Technical Data
© Vanderbilt 2018 41 A6V10276959-d
11.2018

Vanderbilt SPCA210.100 Specifications

General

Brand	Vanderbilt
Model	SPCA210.100
Category	Power Supply
Language	English
