Vanderbilt SPCA210.100 User Manual

Number Description
1 Expanders/PSU
2 Controller
3 Expanders/PSU
4 Battery
An optional external antenna must be fitted to housings with metallic lid if the wireless functionality is
required. If an antenna is fitted to the unit, it must be enabled in the firmware.
The SPC G3 housing provides 3 screw holes for wall mounting the unit (see item 1 below).
Screws with a 4–5mm shank, a minimum head diameter of 8mm and a minimum length of 40mm are
recommended for mounting the housing. Additional expansion plugs or fixings may be required
depending on the construction of the wall.
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Mounting system equipment
© Vanderbilt 2018 45 A6V10276959-d
11.2018

Vanderbilt SPCA210.100 Specifications

General

Brand	Vanderbilt
Model	SPCA210.100
Category	Power Supply
Language	English
