3-108
V
ARI
*L
ITE
®
-
VL4
W
ASH
L
UMINAIRE
S
ERVICE
M
ANUAL
CONFIDENTIAL 02.9628.0010
7-Oct-97
d. Untape connector from cable tie.
e. Maneuver yoke cable or lamp wires so that spring on cable
extends equally from pan tube and tilt tube.
Note
: Cables should only come out of side rail approximately 1 to 1-1/2".
Step 19. Re-assemble luminaire by doing Steps 2 thru 17 in reverse.
