3-10
V
ARI
*L
ITE
®
-
VL4
W
ASH
L
UMINAIRE
S
ERVICE
M
ANUAL
CONFIDENTIAL 02.9628.0010
7-Oct-97
3.1.9 Test Results Charts
Tables 3-2 through 3-9 contain a symptom/probable cause/corrective
action troubleshooting table that isolates faults to the major subassemblies.
Table 3-1 isolates a general luminaire fault to a subassembly. After using
Table 3-1, use Table 3-2 to isolate further.
Table 3-1. Reset Tests (Automatic Tests on Pan and Tilt No Selectable)
Test Parameter Error Codes Results
Pan None 101 No data activity error
102 Data activity error
103 No reset error
Tilt None 201 No data error activity
202 Data activity error
203 No reset error
Table 3-2. Mechanics Tests
Test Parameter Error Codes Results
1 Pan 9 End stop 104 Count does not change Display count last seen.
8 End stop 105 Bit count is not
sequential.
Display received and
expected count.
7 Speed 1
6 Speed 2
5 Speed 3
4 Speed 4
3 Speed 5
2 Speed 6
1 Speed 7
0 Speed 8
2 Tilt 9 End stop 201 Count does not change Display count received
8 End stop 205 Bit count is not
sequential.
Display count received
and expected count.
7 Speed 1
6 Speed 2
5 Speed 3
4 Speed 4
3 Speed 5
2 Speed 6
1 Speed 7
0 Speed 8
To Next Page
