Chapter 4. Illustrated Parts Breakdown
This chapter contains a complete illustrated parts breakdown for the
VL4
wash luminaire All parts are identified by their Vari-Lite part number and
name for the purpose of identification and ordering. This chapter is divided
into the following sections:
4.1 Drawing Tree
4.2 Parts Breakdown
Note
: All parts for each sub-assembly are listed in part number order.
Parts are identified on the corresponding illustration by item numbers. If a
part is used multiple times in different places, the quantity is noted next to
the illustration item number.
