VARILITE VL4 - Yoke B 41 Inch Cable

C
HAPTER
5. W
IRING
D
IAGRAMS
5-17
02.9628.0010 CONFIDENTIAL
7-Oct-97
5.2.8 Yoke “B” 41 Inch Cable (25.9628.0147)
26-Pos Connector (Side A)
Pos. Wire Wire Size Description
1 BLK 24 AWG +20V
2 BRN 24 AWG +20V
3 RED 24 AWG MO 3A
4 ORG 24 AWG MO 3B
5 YEL 24 AWG SENS3
6 GRN 24 AWG MO 4A
7 BLU 24 AWG MO 4B
8 VIO 24 AWG MO 5A
9 GRY 24 AWG MO 5B
10 WHT 24 AWG SENS5
11 BLK/WHT 24 AWG MO 6A
12 BRN/WHT 24 AWG MO 6B
13 RED/WHT 24 AWG H.O.T.
26-Pos Connector (Side B)
Pos. Wire Wire Size Description
1 ORG/WHT 24 AWG +20V
2 YEL/WHT 24 AWG +20V
3 GRN/WHT 24 AWG MO 3C
4 BLU/WHT 24 AWG MO 3D
5 VIO/WHT 24 AWG SENS4
6 GRY/WHT 24 AWG MO 4C
7 RED/BLK 24 AWG MO 4D
8 ORG/BLK 24 AWG MO 5C
9 YEL/BLK 24 AWG MO 5D
10 GRN/BLK 24 AWG SENS6
11 BLU/BLK 24 AWG MO 6C
12 VIO/BLK 24 AWG MO 6D
13 GRY/BLK 24 AWG EARTH GND
