4.2.3.2 Assy, VL4 Upper Enclosure
22.4000.0056
NO. PART NO. QTY DESCRIPTION
1 10.9628.0164 4 EA COVER, FOOT, CHASSIS
2 10.9628.0186 1 EA PAD, MOUNTING, TRANSFORMER
3 22.9628.0056 1 EA ASSY, VL4 UPE CHASSIS
10.9628.0056 1 EA CHASSIS, ELECTRONICS
10.9628.0095 1 EA GUIDE, CARD, OUTSIDE
10.9628.0130 2 EA GUIDE, CARD, MODIFIED PCG-3
22.9637.0093 4 EA ASSY, FASTENER, TRUSS HOOK
10.9620.0269 1 EA STOP, TRUSS HOOK
10.9637.0066 1 EA TRUSS HOOK FASTENER, TOP
10.9637.0067 1 EA TRUSS HOOK FASTENER, BOTTOM
10.9637.0092 1 EA SPACER, TRUSS HOOK FASTENER
55.6700.0001 1 EA HANDLE. SPRING LOADED, 180*SWING AL.
4 22.9628.0171 1 EA ASSY, CARD RETAINER
5 23.9628.0005 1 EA ASSY, TRANSFORMER/CAPACITOR (VL4)
6 25.9628.0150 1 EA CABLE ASSY, INPUT CONN. WIRE (VL4)
7 40.7101.0001 2 EA FILTER, AIR (200S)
8 53.2001.0001 1 EA NUT, 10-32, KEPS ZINC PLATED
9 53.2002.0001 5 EA NUT, 6-32 KEP ZINC PLATED
10 53.2003.0001 4 EA NUT, 4-40, KEP ZINC PLATED
11 53.2004.0001 2 EA NUT, 8-32, KEP
12 53.6524.0002 6 EA SCREW, 6-32X5/16"PPB
13 53.6546.0001 2 EA SCREW, 8-32 X 5/8” PPB
14 53.6564.0001 1 EA SCREW, 10-32x2"PPB
15 53.6600.0001 4 EA SCREW, 4-40X5/16"PPB
16 54.1206.0002 2 EA BUMPER, POLYUR SELF STICKING
17 55.2178.0001 4 EA CABLE ANCHOR MOUNT, #8 SCREW MOUNTING
18 55.2179.0003 1 EA SADDLE, CABLE, ADHESIVE BACKED
19 55.2186.0001 15 EA CABLE TIE, SMALL .10X4"
20 55.6522.0001 2 EA WASHER, FLAT, .750 OD, .192 ID
21 55.6538.0001 2 EA WASHER, LOCK, #6 INTERNAL TOOTH
22 55.6657.0001 1 EA STANDOFF, 1/2"RND 10.32x1" (VL1)
23 55.6696.0003 1 EA BUMPER, RUBBER 1.1/8"O.D. 80 Duro Black
