Assy, Dimmer/Filter/Douser VL4 (continued)
22.4005.0001
NO. PART NO. QTY DESCRIPTION
37 44.6000.0001 1 EA MOTOR, STEPPER .9DEG 48 OHM
38 52.6300.0001 1 EA CONN HOUSING, MTA CLOSE END NATRL 4 PIN
39 52.6383.0001 1 EA CONN, HOUSING, MTA CLOSED END BLU 8 PIN
40 52.6424.0004 1 EA COVER, STRAIN RELIEF/4POS MTA
41 52.6424.0008 1 EA COVER, STRAIN RELIEF/8POS MTA
42 52.8400.0001 1 EA LUG, SOLDER, ANGLE .120 HOLE SZE
43 53.2002.0001 1 EA NUT, 6-32 KEP ZINC PLATED
44 53.2003.0001 1 EA NUT, 4-40 KEP ZINC PLATED
45 53.2009.0001 1 EA NUT, #2-56
46 53.2009.0003 2 EA NUT, 2-56 NYLON INSERT STOP LOCKING
47 53.2301.0001 6 EA PALNUT, 1/2 -13 UNC THRD. X 3/4 OD
48 53.6513.0002 4 EA SCREW, 3MM X 5MM PFZ
49 53.6520.0001 3 EA SCREW, 4-40 X 3/8” PPZ
50 53.6525.0001 1 EA SCREW, 6-32 X 5/16´PPZ
51 53.6559.0001 2 EA SCREW, 4-40 X 1/4” PFZ
52 53.6596.0001 1 EA SCREW, 4-40 X 5/16” PPZ
53 53.6599.0001 2 EA SCREW, 4-40 X 3/8” PFZ
54 53.6601.0002 8 EA SCREW, 4-40 X 3/16”PTH Z
55 53.6659.0002 1 EA SCREW, 2-56 X 1/4” PPZ
56 53.6659.0004 2 EA SCREW, 2-56 X 1/4” PPZ
57 53.6659.006 2 EA SCREW, 2-56 X 3/16” PPZ
58 53.6659.0008 1 EA SCREW, 2-56 X 3/16” PFZ
59 53.6660.0001 1 EA SCREW, 8-32 X 5/16” SLOT HEAD SHOULDER
60 53.6661.0002 2 EA SCREW, 0-80 X 5/16” PPZ
61 54.1208.0001 2 EA BEARING, 1/4”
62 54.2006.0002 2 EA DASHPOT, 1/2” ID X 3/4” L w/1-1/8” ROD
63 54.2007.0001 1 EA RETAINING RING, EXTERNAL 1/4” SHAFT DIA.
64 55.2111.0001 1 EA WASHER, S/S FLAT, .437OD X .159ID X .028THK
65 55.2123.0002 3 EA WAVE SPRING
66 55.2179.0002 2 EA SADDLE, TYWRAP (VL-1)
67 55.2198.0001 1 IN HEAT SHRINK 1/8” BLK
68 55.2203.0001 11 EA SCREW, 4-40 X 1/4” PPZ
69 55.6537.0001 9 EA WASHER, LOCK #4 INTERNAL TOOTH
70 55.6570.0002 1 EA WRM WHL, MLDED 48P 40T 3/16F 1/4” BORE
Delrin
71 55.6603.0001 2 EA SPRING, SS 4.6#/IN. EXTENSION
