C
HAPTER
4. I
LLUSTRATED
P
ARTS
B
REAKDOWN
4-19
02.9628.0010 CONFIDENTIAL
7-Oct-97
4.2.2.7 PCB Assy, VL4 Ignitor (IGN4)
24.9628.0096
NO. PART NO. QTY REF DES DESCRIPTION
1 11.9628.0097 1 EA PCB, VL4 IGNITOR
2 52.6264.0001 1 EA CONN HOUSING, 30 SERIES W/FLNGS 2POS
3 52.6264.0003 1 EA CONN HOUSING, 30 SERIES W/FLNGS 3POS
4 52.8209.0001 4 EA CONTACT, 30 SERIES CONNECTOR POSTED
5 53.2003.0001 2 EA NUT, 4-40, KEP ZINC PLATED
6 53.2016.0002 2 EA NUT, 4-40 HEX ZINC
7 53.6567.0001 2 EA NUT, 4-40 X 1/2” PPZ
8 55.2203.0001 2 EA SCREW, 4-40X1/4"PPZ
9 55.7003.0001 2 EA SPACER, 5/16"RND X 3/16"L, NYLON
10 68.4515.0003 1 EA INDUCTOR, HIGH VOLT, IGNITOR
60.1422.1002 14
EA
R1-R14 RES, 1/4W 5% 10MEG CF
62.2032.0001 1 EA C14 CAP, .01UF, 3000V, RAD, CERAMIC, .375”,
20%
62.3000.0033 13
EA
C1-C13 CAP, .033UF, 1000V, RAD, POLYPRO, .6000”,
10%
75.7102.0001 1 EA SG1 SPARK GAP, 2.5KV
82.4311.0818 12
EA
D1-D12 DIODE, RECTIFIER, MR818 1KV 1A
82.5310.6304 2 EA Z1, Z2 DIODE, Z CLIPPER, 1.5E180CA 180V 5W
