4.2.2.10 Assy, Pan Drive ( VL4 )
22.4001.0001
NO. PART NO. QTY DESCRIPTION
1 10.9620.0005 1 EA WHEEL, WORM, REDUCTION, PAN/TILT
2 10.9620.0101 1 EA SPACER, ADJUSTMENT, BACKLASH
3 10.9620.0105 1 EA PLATE/MOUNT, BEARING/Encoder, PAN & TILT
4 10.9620.0107 1 EA MOUNT, MOTOR, PAN/TILT
5 10.9620.0123 1 EA PULLEY, DRIVE, PAN/TILT
6 10.9620.0270 1 EA SEAL, ENCODER
7 10.9620.0293 1 EA PAD, ANTI-BACKLASH, PTA
8 10.9620.0307 1 EA SHAFT, CLUTCH (NON-ADJ) VL4 & VL2C PAN
9 10.9628.0183 3 EA LEG, MOUNTING, PAN DRIVE
10 22.5007.0001 1 EA ASSY, MAXON MOTOR
10.9620.0006 1 EA WORM, REDUCTION, PAN/TILT
44.5007.0001 1 EA MOTOR, MAXON W/TACH
52.6284.0001 1 EA HEADER, MTA FRCT LOK STRT POST 4 PIN
55.6677.0002 1 EA WASHER, .360OD X .123ID X .025THK, NYLON
11 22.9628.0114 1 EA ASSY, VL4 PAN BOTTOM PLATE
10.9628.0114 1 EA PLATE, BOTTOM, PAN
55.2134.0003 1 EA PLATE, FLOATING NUT
12 45.5101.0001 1 EA ENCODER 256 COUNT
13 52.6424.0008 1 EA COVER, STRAIN RELIEF/8POS MTA
14 52.6434.2208 1 EA CONN, CLOSED W/O TABS 22AWG 8 POS
15 53.2001.0001 1 EA NUT, 10-32, KEPS ZINC PLATED
16 53.2005.0001 2 EA NUT, WHEEL 3/8-32X3/32T
17 53.6513.0001 3 EA SCREW, 2.5MM X 4MM
18 53.6515.0001 1 EA SCREW, 10-32X3/4 SCB SCKT HD CAP
19 53.6516.0001 1 EA SCREW, 10-32 X 3/8"PFZ
20 53.6517.0001 6 EA SCREW, 10-32 X 3/8"PPZ
21 53.6573.0001 2 EA WASHER, SS, .750OD X.375ID X.060
22 53.6591.0001 1 EA SCREW, 6-32X1/4"PFZ
23 53.6592.0002 4 EA SCREW, 4-40X1/2"SCB
24 54.1201.0001 6 EA BUSHING
25 54.1208.0001 2 EA BEARING, 1/4"
26 55.2114.0001 6 EA WASHER, LCK INT TTH #10
27 55.2123.0001 1 EA SPRING, WAVE 1/4"
28 55.2124.0001 2 EA SPRING, CURVE (HIGH CARBON)
29 55.2125.0001 1 EA STANDOFF, 3/8"SQR 10-32x1 5/16"
30 55.2133.0001 2 EA STANDOFF, 5/16"HEX 10-32X1-5/16"SP
31 55.2186.0001 2 EA CABLE TIE, SMALL .10X4”
