4.2.2.11 PCB Assy, VL4 Yoke Cable Term (YTB)
24.9628.0049
NO. PART NO. QTY DESCRIPTION
1 11.9628.0050 1 EA PCB, VL4 YOKE CABLE TERMINATION
2 52.6259.0001 1 EA HEADER, MTA FRCT LOK STRT POST 5PIN
3 52.6284.0001 8 EA HEADER, MTA FRCT LOK STRT POST 4PIN
4 52.6296.0001 6 EA HEADER, MTA FRCT LOK STRT POST 8PIN
5 52.6420.0026 2 EA PIN HEADER ASSY, WO/LATCH 26POS
6 52.6421.0027 4 EA LATCH w/o PUSH TABS for Pin Header Assy
7 53.2003.0001 1 EA NUT, 4-40, KEP ZINC PLATED
8 53.6591.0001 1 EA SCREW, 6-32X1/4"PFZ
9 53.6633.0001 4 EA SCREW, 4-1/4"PPZ SHT METAL
10 60.1431.1803 6 EA RES, 1/4W 5% 180 CF
11 74.1006.0004 1 EA SWITCH, THERMAL 100*C PCB MOUNT
12 82.4312.0105 2 EA DIODE, FAST ,MUR105/110 50V 1A
