4-50
V
ARI
*L
ITE
®
-
VL4
W
ASH
L
UMINAIRE
S
ERVICE
M
ANUAL
CONFIDENTIAL 02.9628.0010
7-Oct-97
4.2.3.15 PCB Assy,
VL4
Interface (IFB)
24.9628.0082
NO. PART NO. QTY REF DES DESCRIPTION
1 11.9628.0083 1 EA PCB, VL4 INTERFACE
2 52.6246.0002 1 EA P1 CONN,64PIN TYPE C RT W/MFBL PIN
3 52.6423.0096 1 EA P2 CONN, EURO 96POS TYPE R
50.2708.0001 3 EA XU5, 6, 12 SOCKET, 8PIN DIP
50.2714.0001 7 EA XU2, 13.18 SOCKET, 14PIN DIP
50.2716.0001 7 EA XU7.10, 19.21 SOCKET, 16PIN DIP
50.2720.0001 9 EA XU1, 22, 23, 30.35 SOCKET, 20PIN DIP
50.2724.0002 2 EA XU3, 4 SOCKET, 24PIN DIP .3" CENTERS
50.2728.0001 1 EA XU11 SOCKET, 28PIN DIP
51.5012.0001 2 EA AP: Q1, 2 HEATSINK, TO.220 0.50"TALL (VL4)
51.5012.0002 2 EA AP: Q1, 2 INSULATOR, TO.220, NARROW, MICA
52.6373.0003 12 EA AP: AU24.29 SOCKET STRIP, SNGL ROW 8PIN
53.2003.0001 2 EA AP: Q1, 2 NUT,4-40, KEP ZINC PLATED
53.6520.0001 2 EA AP: Q1, 2 SCREW,4-40X3/8"PPZ
53.6545.0004 3 EA SCREW, 8-32X3/8"PPZ
55.6509.0001 2 EA AP: Q1, 2 WASHER, SHOULDER (HEATSINK)
60.1222.1504 4 EA R7, 8, 10, 11 RES, 1/4W 1% 15K CF
60.1224.1002 8 EA R1, 2, 12.15, 20, 21 RES, 1/4W 1% 10.0K CF
60.1227.4993 2 EA R5, 6 RES, 1/4W 1%4.99K
60.1421.4701 5 EA R9, 16.19 RES, 1/4W5%4.7K CF
60.1429.3305 2 EA R3, 4 RES, 1/4W5%330K CF
61.4306.0102 1 EA RP1 RES SIP, 1026PIN BUSSED LW PRFLE
61.4308.0272 1 EA RP2 RES SIP, 272 8PIN BUSSED LW PRFLE
61.4310.0102 1 EA RP3 RES SIP, 102 10PIN BUSSED LW PRFLE
62.2013.0104 35 EA C2.5, 7, 8, 11.32, 34.40 CAP, .1UF,50V,AXL,CERAMIC, .100",20%
62.2015.0474 2 EA C1, 6 CAP, .47UF,50V,SIP,CERAMIC, .100",20%
62.2099.0103 2 EA C9, 10 CAP, .01UF,50V,SIP,CERAMIC, .100",10%
66.4501.0001 1 EA RY1 RELAY, DPDT, 2A,5VDC, PC. MNT, SEALED
80.1512.0112 2 EA Q1, 2 TRANSISTOR, TIP112 NPN 100V 2A TO220
80.2513.0005 1 EA Q3 TRANSISTOR, MPSA05 NPN60V500MA
TO92
82.4306.4001 1 EA D1 DIODE, RECTIFIER, 1N400150V 1A
82.5311.5357 6 EA ZD1.6 DIODE, ZENER , 1N5357A/B 20V5W
83.3102.0001 2 EA U5, 6 IC, LF442 DUAL JFET OP AMP
83.3105.0001 1 EA U13 IC, LM339 COMPARATOR
83.3117.0001 1 EA U12 IC, LM393 DUAL COMPARATOR
83.3154.0558 1 EA U8 IC, AD558 ANALOG.DIGITAL CONVERTER
84.4109.0002 1 EA U11 IC, HD63B40P PROG.TIMER MODULE
(CMOS)
84.4130.0001 1 EA U16 IC, 74HC04 HEX INVERTER
84.4131.0001 1 EA U17 IC, 74HC05 HEX INVERTER W/OPEN
COLLECTOR
84.4132.0001 1 EA U15 IC, 74HC08 QUAD 2.INPUT AND GATE
84.4133.0001 1 EA U21 IC, 74HC1383.TO.8 DECODER
84.4134.0001 1 EA U2 IC, 74HC14 HEX INV. SCHMIDT TRIGGER
84.4138.0001 1 EA U7 IC, 74HC175 QUAD D FLIP FLOP
