C
HAPTER
4. I
LLUSTRATED
P
ARTS
B
REAKDOWN
4-53
02.9628.0010 CONFIDENTIAL
7-Oct-97
4.2.3.17 Assy, APS+ Chassis (
VL4
)
23.9628.0029
NO. PART NO. QTY DESCRIPTION
1 10.9620.0157 2 EA PAD, CHOKE, APS
2 10.9628.0030 1 EA CHASSIS, APS+
3 10.9628.0206 1 EA PAD, INSULATOR, APS+
4 10.9628.0229 2 EA INSULATOR, CHASSIS SIDE, APS+
5 11.9620.0163 1 EA PCB, CAPACITOR TERMINATION
6 46.6003.0001 1 EA MOUNTING DISC, METAL 60MM DIA
7 52.6375.0001 1 EA CAP HOUSING, MNLOK 6POS
8 52.8244.0002 6 EA FASTON RECEPT FLAG,.250 16-14AWG (LOOSE)
9 52.8258.0001 6 EA CONTACT PIN, 20-14AWG MNLOK (LOOSE)
10 53.2002.0001 1 EA NUT, 6-32 KEP ZINC PLATED
11 53.6558.0001 1 EA SCREW, 6-32X3/8"PPZ
12 53.6569.0003 2 EA RIVET, ALUM COUNTERSINK 3/16"X1/2"
13 55.2114.0001 4 EA WASHER, LCK INT TTH #10
14 55.2186.0001 8 EA CABLE TIE, SMALL .10X4" (Not Shown)
15 55.2197.0001 1 IN HEAT SHRINK 3/8" BLACK (Not Shown)
16 55.6564.0001 4 EA SCREW, 10-32X5/16"PPZ
17 60.4430.4702 2 EA RES, 2W 5% 47K MF
18 62.2028.0471 2 EA CAP, 470UF, 200V,RAD,ALUMNUM, .500",REF
19 67.4001.0001 1 EA FILTER, EMI 250V 10A (CORCOM 10K1)
20 68.4516.0001 1 EA CHOKE, TOROID 110 TURNS
21 73.7006.0001 2 IN WIRE, 16AWG STRND BLACK
22 73.7010.0001 12 IN WIRE, 16AWG STRND GRAY
23 73.7012.0001 12 IN WIRE, 16AWG STRND RED
24 73.7016.0001 12 IN WIRE, 16AWG STRND WHITE/BLACK STRIPE
25 73.7053.0001 7 IN WIRE, 16AWG RED/BLACK STRIP
26 82.4303.2506 1 EA BRIDGE RECTIFIER, MDA2506 600V 25A
To Next Page
