VARILITE VL4 - Page 214

4-60
V
ARI
*L
ITE
®
-
VL4
W
ASH
L
UMINAIRE
S
ERVICE
M
ANUAL
CONFIDENTIAL 02.9628.0010
7-Oct-97
4.2.3.21 PCB Assy, APS+ Current Sense
24.9628.0197
NO. PART NO. QTY REF DES DESCRIPTION
1 10.9628.0241 1 EA HEAT SINK, CURRENT SENSING RESISTOR
VL4
2 11.9628.0198 1 EA PCB, APS+ CURRENT SENSE
3 73.7088.0001 9 IN WIRE, 26AWG TW.PR BLU/WHT SOLID,TINNED
52.6373.0003 1 EA SOCKET STRIP, SNGL ROW 8PIN
52.8241.0001 4 EA AP: R52A, 52B PIN CONTACT, 16AWG GOLD
55.2199.0001 1 IN HEATSHRINK, 1/16" BLACK
60.1230.2003 4 EA R54.57 RES, 1/4W 1% 200K MF
60.7242.0501 2 EA R52A, 52B RES, 5W 1% .05 WW
62.2063.0180 1 EA C30 CAP, 18PF, 500V,RAD,DIPMICA, .234", 5%
63.2012.0002 2 EA TR2, 3 POT, 10K,LIN, 1TRN, VERT MNT, 10%
1
2
3
