Table 3-9 General Error Codes
Error
Number
Error for PSU Test (15)
MSC = F
NSC = Parameter
LDC = Error Number
Error for Mechanics
Tests (1 to 11)
MSC = Test Number
NSC + LSC = Error
Number
Results Associated With
Mechanics Error Codes
(After Error Code)
01 IPRES No data activity error
02 PSOT Data activity error
03 HOT No reset error
04 SHORT Count does not change Display count last seen
05 NOT IPRES Bit count is not sequential Display received and
expected count
11 Sensor hit too early,
motion impeded
12 Backlash too small (0)
13 Backlash too large. Indicate backlash value
(half steps in
hexadecimal)
14 Sensor not hit, motion
impeded, sensor
permanently high
15 Sensor permanently low
