3-34
V
ARI
*L
ITE
®
-
VL4
W
ASH
L
UMINAIRE
S
ERVICE
M
ANUAL
CONFIDENTIAL 02.9628.0010
7-Oct-97
Step 4. Remove lamp assembly from head.
a. At lamp access plate, turn 1/4-turn fasteners to open lamp
access plate and slide out lamp assembly.
CAUTION
: When removing bulkhead, make sure that connectors do not
get caught on yoke termination board.
Step 5. Remove blue/amber bulkhead.
a. At blue/amber bulkhead, using 5/16 inch nutdriver, remove
two 6-32 KEPS nuts that secure bulkhead to male studs on
rail covers.
b. Slide bulkhead out of luminaire head.
Step 6. Replace blue/amber bulkhead by doing Steps 2 thru 5 in
reverse.
