VAT 615 Series

Installation, Operating & Maintenance Instructions
Series 615 DN 40 (I.D. 1½”), DeviceNet
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel +41 81 771 61 61 Fax +41 81 771 48 30 CH@vatvalve.com www.vatvalve.com
603476EA
2013-07-25
100/102
8.4 Accessories
Item
Description
Part number
24 VDC power supply unit
(input: 100 – 240 VAC)
249775
‘Control Performance Analyzer’
package for Windows
®
consisting of software and cable
600SP-99LB-000
‘Control View’ software for
Windows
®
248126
free download from www.vatvalve.com
or
available on order against charge
Service cable
(PC to valve connection)
230327
free wiring information available for download from www.vatvalve.com
Connector kit consisting of:
DB-9 female POWER plug
DB-15 male SENSOR plug
DB-25 male INTERFACE plug
242411
Service Box 2
601BS-29NN-000
Control panel (rack-mount
version of Service Box 2)
602BS-29LE-000
Special Allen wrench for
disassembly and assembly
244873
8.4.1 Centering ring with Viton o-ring
Description
Valve size
Product ordering number
DN 40 / 1½"
61532 - . . . . - . . . .
Centering ring
with Viton o-ring
(for ISO-KF and
ISO-F installation
only)
Aluminum
32034-KAZV
Stainless steel
32034-KEZV
