3.10.1 Pressure control operation with 2 sensors
[applicable with 615 . . - . . . Q - . . . . version only]
If 2 sensor operation is enabled, changeover between the sensors is done automatically during pressure control. For
configuration refer to chapter «Setup procedure». We recommend a ratio of 10:1 between the pressure gauges. Max. ratio
is 100:1. High range respectively low range pressure gauge may be either connected to sensor 1 or sensor 2 input.
It’s required to do correct sensor configuration.
Between 90 and 100% of the low range sensor full scale, the low range sensor is phased out while high range sensor is
phased in during pressure rise. During pressure decrease the high range sensor is phased out while low range sensor is
phased in. This maintains a functional response behavior in case of small calibration errors between the two sensors. The
PRESSURE output in this range is a blend between both sensors.
For monitoring purpose each sensor signal may be read out individually. Refer to «Explicit messaging inquiry commands
SENSOR 1 READING and SENSOR 2 READING».
Note: Make sure that both sensors are calibrated.
Note: Do not close optional gauge isolation valves during the transition phase between the sensors.
3.11 Tuning of pressure control performance
Tuning of pressure control performance with adaptive algorithm, refer to chapter: 3.11.1 Tuning of pressure
control with adaptive algorithm.
Tuning of pressure control performance with Fixed algorithm, refer to chapter: 3.11.2 Tuning of pressure control
performance with Fixed algorithm.
Tuning of control performance with Soft pump control, refer to chapter: 3.11.3 Tuning of control performance with
soft pump algorithm
