4.10 S-Device Supervisor Object (Class ID 48)
Command
Service Code
Class ID
Instance ID
Attribute ID
Service
data length
(number of
bytes)
Service
data field
Description
EXECUTING
6
48
1
-
3
X
This command changes the valve to executing state.
Note: EXECUTING must to be selected to enable for all executing commands such as
control mode, close valve and open valve.
Note: If valve is already in executing state and anew EXECUTING command is sent
DeviceNet® will return an error message.
IDLE
7
48
1
3
-
-
This command changes the valve to idle state.
DEVICE STATUS
Get
14
48
1
11
1
X
X: 1 self test
2 idle
3 self test exception
4 executing
5 abort
This command returns the device status.
EXCEPTION STATUS
Get
14
48
1
12
1
The exception status byte only indicates that alarms or warnings are present. For details see
EXCEPTION DETAIL ALARM resp. EXCEPTION DETAIL WARNING.
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
1
Manufacturer
specific
warning
reserved
reserved
reserved
Manufacturer
specific alarm
reserved
reserved
