3.6.4 Valve configuration
Basic valve configuration must be adapted according to application needs.
Definition of valve plate position (CLOSE or OPEN) after power up sequence. Default is ‘open‘.
Definition of valve plate position (CLOSE or OPEN) in case of a power failure. Default is ‘not defined‘.
Only for versions that have Power Fail Option equipped [615 . . - . . C . - . . . . or 615 . . - . . H . - . . . . ].
ZERO function. This may be ‘disabled’ or ‘enabled’. Default is ‘enabled‘. Refer also to «ZERO (setup step 4)».
Local operation:
(‘Control View’, ‘Control Performance Analyzer’ or
Service Box2)
Remote operation:
1. Open CV, CPA or SB2
Refer to chapter: «Pressure Controller Object» for details.
2. Switch to [LOCAL]
3. Do the Power Up configuration in menu
‘Setup / Valve’.
3.6.5 Sensor configuration
Sensor configuration for 2 sensor version [615 . . - . . . Q - . . . .].
Refer also to «Pressure control operation with 2 sensors».
Local operation:
(‘Control View’ or ‘Control Performance Analyzer’ or
Service Box2)
Remote operation:
1. Open CV, CPA or SB2
(Refer to chapter «S-Analog Sensor Object» for details)
2. Switch to [LOCAL]
3. Enable or disable ZERO function in menu
‘Setup / Sensor’. / ’ZERO’
4. Do 2 sensor configuration in menu
‘Setup / Sensor’.
1. Select Sensor Type
2. Select Sensor Full Scale
