Installation, Operating & Maintenance Instructions
Series 615 DN 40 (I.D. 1½”), DeviceNet
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel +41 81 771 61 61 Fax +41 81 771 48 30 CH@vatvalve.com www.vatvalve.com
603476EA
2013-07-25
29/102
3.6.3 LOGIC I/O configuration
Default configuration for LOGIC I/O is:
#
Function
Mode
Input
Digital input
close valve
non inverted
enabled
#
Function
Mode
Output
Digital output
close
non inverted
enabled
The «LOGIC I/O» Digital input and Digital output can be adjusted.
Local operation:
(‘Control View’, ‘Control Performance Analyzer’ or Hyper terminal)
Remote operation:
1. Open CV or CPA
2. Switch to [LOCAL]
3. Go to «Tools» > «Terminal» and send setup command according
to application needs. (possibility of adjustment see below)
For Digital input:
to change the configuration: s:2601abcdef[CR]
to read the configuration: i:2601[CR]
Note: Each element is separated with square brackets for clarity.
Square brackets are not part of command syntax. All elements are
ASCII characters. There are no spaces between the elements
necessary. Command is case sensitive.
data length 6 characters
a 0 = close valve
1 = open valve
b 0 = non inverted
1 = inverted
c 0 = enabled
1 = disabled
def 000 (reserved)
For Digital output:
to change the configuration: s:2611abcdef[CR]
to read the configuration: i:2611[CR]
data length 6 characters
a 0 = close
1 = open
2 = On
b 0 = non inverted
1 = inverted
c 0 = enabled
1 = disabled
def 000 (reserved)
For LOGIC I/O connector schematics see also chapter «LOGIC I/O».
Note: It’s not possible to configuration in
remote operation.
