Object Name
Class Code (dec)
Maximum
Instances
Attribute ID
Pressure Controller
100
1
101 Cycle Counter
103 Device Status
106 Isolation Cycle Counter
107 Access Mode
112 Synch Endposition
113 PFO Endposition
4.5 Identity Object (Class ID 1)
The Identity Object (Class Code 01) provides general information about the device as defined in the ODVA DeviceNet
Specification, Volume II [2]
Command
Service Code
Class ID
Instance ID
Attribute ID
Service
data length
(number of bytes)
Service
data field
Description
RESET
5
1
1
-
1
X
X:
0 = This command resets the DeviceNet
®
interface.
1 = This command resets the DeviceNet
®
interface to factory default settings.
Note: All previously done configurations will be overwritten.
4.6 Assembly objects (Class ID 4)
Command
Service Code
Class ID
Instance ID
Attribute ID
Service
data length
(number of bytes)
Service
data field
Description
ASSEMBLY OBJECTS
Set
16
4
X
3
Y
Z
Get
14
X, Y: depending on respective assembly, refer to «Assembly description» for details.
Z: Data
Use Assembly Type Input for «Set» command, and Assembly Type Output for «Get» command.
This command writes/reads the respective assembly object in Explicit Mode.
Note: Factory default assemblies are: Input assembly 3 / Output assembly 8
