8 Spare parts
Please specify the fabrication number of the valve (see yellow label on valve) when ordering spare parts.
This is to ensure that the appropriate spare parts are supplied.
8.1 Valve unit
All «Item» refer to chapter: «Drawing»
Item
Description
1
Spare parts kit body with mechanism complete
462153
2
Spare parts kit lever complete
511515
3
Spare parts kit adapter flange, rod with bearing
453094
5
Plate screws (2x)
428946
6
Body complete
443048
7
Plate
428257
For versions such as: Other valve sizes or heated valves, spare part ordering numbers are available on request.
8.2 Seal kit
Item
Description
4
Rotary feed through seals kit
237235
Rotary feed through seals
atmosphere (Viton
®
)
N-5100-204
vacuum (Viton
®
)
N-5100-204
8
Plate O-ring (FKM, e.g. Viton
®
)
365576
Vacuum grease
206792 (2ml), 206793 (5ml)
